Profec Non return valve stainless steel 316 2" female thread 40bar
Part number 0080297
Manuals & drawings
Frequently bought together
Technical details
-
Material housingstainless steel 316
-
Material sealPTFE
-
Max. temp.200 °C
-
Connectionfemale thread
-
Material (spring)stainless steel 316
-
Pressure40 bar
-
Opening pressure0,1 bar
-
Valve shapeflap
-
Materialstainless steel 316
-
EAN4019305013796
-
Part number0080297
-
ManufacturerProfec
Dimensions
-
F-125 mm
-
F-225 mm
-
L151 mm
-
Lb151 mm
-
ØDi-12 "
-
ØDi-22 "
Similar products
Product description
The Non return valve spring loaded is a loaded Y-pattern spring loaded valve made from Stainless Steel 316. It is available with a Stainless Steel 304 spring and PTFE seals. it is used by professionals for domestic and industrial projects but also for agricultural and watertreatment projects.
The Non return valve is available in a wide variety of Female x Female BSP thread connections, with a working pressure of 40 bar. It can be used for projects with a maximum temperature range up to 200 degrees.
Profec is a professional brand, mostly used for different water related projects.
