Profec Ball valve brass nickel plated 1/4" female thread 25bar type 100 VA

Part number 0403030
Profec Ball valve brass nickel plated 1/4" female thread 25bar type 100 VA
Profec Ball valve brass nickel plated 1/4" female thread 25bar type 100 VA

Manuals & drawings

Select your item below or order directly via full product table
Size
All displayed prices are gross. Please log in or contact sales for custom pricing.
Price to pay excl. VAT €8.54 / 1 pcs
€8.54 / pcs
Price to pay incl. VAT €10.33 / 1 pcs
€10.33 / pcs
508 in stock in Veghel, NL - Item %s is ready to ship, minimum delivery time: %s working days
pcs
Box qty:
216 pcs
MSQ:
1 pcs

Frequently bought together

Itap Drain valve brass nickel plated 1/4" male thread type 194
0710221
Itap Drain valve brass nickel plated 1/4" male thread type 194

€3.46
Profec 2-piece ball valve stainless steel 316 1/4" female thread 64bar DIN3202-M3
7034103
Profec 2-piece ball valve stainless steel 316 1/4" female thread 64bar DIN3202-M3

€13.13
Profec Nr. 23 Pipe nipple brass 1/4" male thread 40bar 100 mm
0701803
Profec Nr. 23 Pipe nipple brass 1/4" male thread 40bar 100 mm

€18.61
Profec Nr. 310 Nut brass 1/4" female thread 30bar
0710405
Profec Nr. 310 Nut brass 1/4" female thread 30bar

€2.21
Profec Nr. 270 Socket brass 1/4" female thread 30bar
0710367
Profec Nr. 270 Socket brass 1/4" female thread 30bar

€3.47
Profec Nr. 90 Elbow 90° brass 1/4" female thread 30bar
0710284
Profec Nr. 90 Elbow 90° brass 1/4" female thread 30bar

€5.45
Profec Plug brass 1/4" male thread 10bar
0410332
Profec Plug brass 1/4" male thread 10bar

€3.09
Tefen Socket PA glass fibre reinforced 1/4" female thread 14bar blue
7030229
Tefen Socket PA glass fibre reinforced 1/4" female thread 14bar blue

€1.40
Profec Nr. 130 T-piece 90° brass 1/4" female thread 30bar
0710306
Profec Nr. 130 T-piece 90° brass 1/4" female thread 30bar

€7.23
Profec Nr. 270 Socket cast iron galvanised 1/4" female thread 25bar DVGW
1027002
Profec Nr. 270 Socket cast iron galvanised 1/4" female thread 25bar DVGW

€5.30

Technical details

  • Material
    brass
  • Colour lever
    red
  • Pressure
    25 bar
  • Surface treatment
    nickel plated
  • Operation
    lever
  • Material seal
    PTFE
  • Connection
    female thread
  • Handle material
    stainless steel
  • Type
    100 VA
  • Temperature range
    0°C - 100°C
  • Ball material
    hard chrome plated brass
  • EAN
    4019305394932
  • Part number
    0403030
  • Manufacturer
    Profec

Dimensions

  • Ct-1
    42 mm
  • F-1
    9.5 mm
  • F-2
    9.5 mm
  • Lb
    41.5 mm
  • R
    89 mm
  • ØDf
    10 mm
  • ØDi-1
    1/4 "
  • ØDi-2
    1/4 "
Technical drawing

Barcode

4019305394932

Variants

Part number
Price
Box qty
MSQ
Stock
No variants found
Adjust or clear the selected filters to see available variants.
0403030
€8.54
216
1
(508)
0403031
€8.02
144
1
0403032
€11.78
96
1
(3765)
0403033
€18.42
84
1
0403034
€24.15
48
1
0403035
€42.30
24
1
0403036
€55.80
24
1
0403037
€86.02
16
1
(462)
0403038
€177.83
4
1
(150)
0403039
€270.87
2
1
0403040
€383.72
2
