Non return valve spring loaded stainless steel 316 3/4" female thread 15bar DN20

Part number 0081493

Manuals & drawings

Shop the full range here
All displayed prices are gross. Please log in or contact sales for custom pricing.
Price to pay incl. VAT €107.74 / 1 pcs
€107.74 / pcs
Price to pay excl. VAT (€89.04 / 1 pcs)
Box qty:
1 pcs
MSQ:
1 pcs
Available from supplier, please contact us
pcs

Frequently bought together

Itap Non return valve spring loaded brass 3/4" female thread 12bar DN20 type York 103
Itap Non return valve spring loaded brass 3/4" female thread 12bar DN20 type York 103

€13.87
Profec Foot valve spring loaded brass 3/4" female thread 10bar DN20 stainless steel 304
Profec Foot valve spring loaded brass 3/4" female thread 10bar DN20 stainless steel 304

€10.85
Foot valve spring loaded PA 3/4" female thread 10bar white type 2720
Foot valve spring loaded PA 3/4" female thread 10bar white type 2720

€12.31
Non return valve PA 3/4" female thread 10bar white type 2700
Non return valve PA 3/4" female thread 10bar white type 2700

€14.37
Itap Ball valve brass nickel plated 3/4" female thread 5bar DN20 DVGW type 068
Itap Ball valve brass nickel plated 3/4" female thread 5bar DN20 DVGW type 068

€20.93
Profec Nr. 270 Socket stainless steel 316 3/4" female thread 16bar
Profec Nr. 270 Socket stainless steel 316 3/4" female thread 16bar

€16.03
Globe valve top brass 3/4" male thread 10bar DN20 type 1801
Globe valve top brass 3/4" male thread 10bar DN20 type 1801

€12.45
Profec Nr. 312 Nut stainless steel 316 3/4" female thread 16bar
Profec Nr. 312 Nut stainless steel 316 3/4" female thread 16bar

€8.88
Profec Nr. 120 Elbow 45° stainless steel 316 3/4" female thread 16bar
Profec Nr. 120 Elbow 45° stainless steel 316 3/4" female thread 16bar

€19.52
Profec Ball valve PVC-U 3/4" female thread 16bar DN25 grey type Safe 625
Profec Ball valve PVC-U 3/4" female thread 16bar DN25 grey type Safe 625

€14.62

Technical details

  • Pressure
    15 bar
  • Material housing
    stainless steel 316
  • Material seal
    PTFE
  • Connection
    female thread
  • Length
    60 mm
  • Material (spring)
    stainless steel 316
  • Max. temp.
    110 °C
  • DN
    20
  • Opening pressure
    0,1 bar
  • Diameter
    20 mm
  • Material
    stainless steel 316
  • EAN
    4019305353885
  • Part number
    0081493
  • Manufacturer
    Unbranded

Dimensions

  • L
    60 mm

h1web-bosta-customizations.pdp.similarProducts.title

Non return valve spring loaded stainless steel 316 3/4" female thread 16bar DN20 type M316
Non return valve spring loaded stainless steel 316 3/4" female thread 16bar DN20 type M316

€77.51
Profec Non return valve stainless steel 316 3/4" female thread 40bar
Profec Non return valve stainless steel 316 3/4" female thread 40bar

€133.12
Itap Non return valve spring loaded brass 3/4" female thread 12bar DN20 type York 103
Itap Non return valve spring loaded brass 3/4" female thread 12bar DN20 type York 103

€13.87
Profec Foot valve spring loaded brass 3/4" female thread 10bar DN20 stainless steel 304
Profec Foot valve spring loaded brass 3/4" female thread 10bar DN20 stainless steel 304

€10.85
Itap Foot valve spring loaded brass 3/4" female thread 25bar DN20 stainless steel 304 type Europa 105
Itap Foot valve spring loaded brass 3/4" female thread 25bar DN20 stainless steel 304 type Europa 105

€26.08
Profec Non return valve brass 3/4" female thread 16bar DN20 type 790
Profec Non return valve brass 3/4" female thread 16bar DN20 type 790

€18.31
Non return valve brass 3/4" female thread 10bar DN20 type 425
Non return valve brass 3/4" female thread 10bar DN20 type 425

€80.10
Profec Non return valve brass 3/4" female thread 10bar DN20 type F
Profec Non return valve brass 3/4" female thread 10bar DN20 type F

€37.35
Itap Non return valve brass 3/4" female thread 25bar DN20 type Roma 104
Itap Non return valve brass 3/4" female thread 25bar DN20 type Roma 104

€29.58
Itap Non return valve brass 3/4" female thread 25bar DN20 type Europa 100
Itap Non return valve brass 3/4" female thread 25bar DN20 type Europa 100

€18.35

Product description

The Non return valve spring loaded is made from Stainless Steel 316 and suitable for domestic and agricultural projects.

It has a Female x Female BSP thread connection and a 40 bar working pressure.

Read more Read less

Barcode

4019305353885

Variants

Part number
Price
Box qty
MSQ
Stock
0081492
€89.04
1
1
0081493
€89.04
1
1
0081494
€89.04
1
1
