Globe valve brass 1/2" female thread 10bar DN15 DVGW type 1110

Part number 0400665
Skip image gallery
Globe valve brass 1/2" female thread 10bar DN15 DVGW type 1110

Manuals & drawings

Select your item below or order directly via full product table
Size
All displayed prices are gross. Please log in or contact sales for custom pricing.
Price to pay excl. VAT €31.55 / 1 pcs
€31.55 / pcs
Price to pay incl. VAT €38.18 / 1 pcs
€38.18 / pcs
10 in stock in Veghel, NL - Item %s is ready to ship, minimum delivery time: %s working days
pcs
Box qty:
1 pcs
MSQ:
1 pcs

Frequently bought together

Globe valve top brass 1/2" male thread 10bar DN15 type 1801
0410310
Globe valve top brass 1/2" male thread 10bar DN15 type 1801

€8.50
Quick coupler brass CW617N 1/2" female thread CD 40 10bar DN15 KTW-A
7019053
Quick coupler brass CW617N 1/2" female thread CD 40 10bar DN15 KTW-A

€12.04
Profec Ball valve single union PVC-U 1/2" female thread 10bar DN15 grey type Safe 550
0112150
Profec Ball valve single union PVC-U 1/2" female thread 10bar DN15 grey type Safe 550

€8.89
Profec Ball valve PVC-U 1/2" female thread 16bar DN15 grey type Safe 625
0112110
Profec Ball valve PVC-U 1/2" female thread 16bar DN15 grey type Safe 625

€11.35
Non return valve PA 1/2" female thread 10bar white type 2700
0440855
Non return valve PA 1/2" female thread 10bar white type 2700

€12.02
Profec Click connector brass 1/2" female thread x male click
0500108
Profec Click connector brass 1/2" female thread x male click

€4.74
Profec Quick coupler brass 1/2" female thread CD 40 12bar
0420112
Profec Quick coupler brass 1/2" female thread CD 40 12bar

€6.47
Plug valve PP 1/2" male thread x female thread 6bar black
7038704
Plug valve PP 1/2" male thread x female thread 6bar black

€2.54
Bonfix Safety valve brass 1/2" male thread x female thread 3bar KIWA
0709211
Bonfix Safety valve brass 1/2" male thread x female thread 3bar KIWA

€10.37
Nr. 94 Elbow 90° brass 1/2" male thread 10bar
0420508
Nr. 94 Elbow 90° brass 1/2" male thread 10bar

€9.98

Technical details

  • Approval
    DVGW
  • Material
    brass
  • Material seal
    EPDM
  • Pressure
    10 bar
  • DN
    15
  • Connection
    female thread
  • Colour lever
    green
  • Type
    1110
  • Material valve
    brass
  • Length
    65 mm
  • Max. temperature
    90 °C
  • Material housing
    brass
  • Handle material
    polyamide
  • Max. temp.
    90 °C
  • Operation
    handwheel
  • EAN
    4019305340748
  • Part number
    0400665

Dimensions

  • Ct-1
    64 mm
  • F-1
    12 mm
  • F-2
    10 mm
  • L
    65 mm
  • Lb
    65 mm

Barcode

4019305340748

Variants

Part number
Price
Box qty
MSQ
Stock
No variants found
Adjust or clear the selected filters to see available variants.
0400665
€31.55
1
1
(10)
0400666
€52.42
1
1
0400667
€59.66
1
1
(5)
