Itap Non return valve brass 3/8" female thread 25bar DN10 type Roma 104
Part number 0405210
Downloads
Select your item below or order directly via
full product table
All displayed prices are gross. Please log in or contact sales for custom pricing.
Excl. VAT
10,23 € / 1 pcs
10,23 € / pcs
Incl. VAT
10,23 € / 1 pcs
10,23 € / pcs
118 in stock in Veghel, NL
- minimum delivery time: 10 working day(s)
Frequently bought together
0730003
0090894
Technical details
-
DN10
-
Materialbrass
-
Pressure25 bar
-
Length63 mm
-
Temperature range-20°C - 100°C
-
Connectionfemale thread
-
Material housingbrass
-
TypeRoma 104
-
Material sealviton
-
Material (spring)stainless steel 302
-
EAN4019305106092
-
Part number0405210
-
ManufacturerItap
Dimensions
-
Ct-129 mm
-
F-111 mm
-
F-211 mm
-
H48.5 mm
-
L110 mm
-
Lb62 mm
-
ØDi-13/8 "
-
ØDi-212 mm
Similar products
Product description
The Itap Non return valve spring loaded type Roma 104, also known as the Roma check valve, are suitable for different water related applications, heating and air-conditioning applications and compressed air systems.
The Itap Non return valve spring loaded type Roma 104 can be installed in various directions: horizontally, vertically and oblique. The body contains brass material. The Itap Non return valve spring loaded type Roma 104 is available with an outlet plugs that are made from brass.
Itap is a Italian manufacturer known for its high quality assortment.
