Tefen Dosing pump 1" x 10 mm x 1" male thread x hose tail x male thread type MixRite TF5 0.2% - 2%
Part number 7024294
Downloads
All displayed prices are gross. Please log in or contact sales for custom pricing.
Incl. BTW
976,74 € / 1 pcs
976,74 € / pcs
Excl. VAT (976,74 € / 1 pcs)
Excl. VAT (976,74 € / 1 pcs)
Packed per:
1 pcs
MSQ:
1 pcs
Frequently bought together
7029460
NaanDan Leakage prevention device plastic 3/8" bayonet F x male thread black type Low-Pressure with filter
Subscription
Op voorraad
1,63 €
7020935
NaanDan Mounting device plastic 4/7 mm taper M x push-in 3bar type Flipper
Subscription
Out of stock
0,83 €
7042747
1029004
Profec Nr. 290 Plug cast iron galvanised 1/2" male thread 25bar DVGW
Subscription
Out of stock
0,46 €
0303179
Pressure pipe PVC-U 32 mm x 1,6 mm glue socket x plain 10bar ISO-PN10 grey 5m
Subscription
Op voorraad
1,06 €
0410730
Technical details
-
Connectionmale thread x hose tail x male thread
-
TypeMixRite TF5
-
Size1" x 10 mm x 1"
-
EAN4019305681865
-
Part number7024294
-
ManufacturerTefen
Product description
All units have a standard hydraulic On/Off system, for manual and electric alternatives please consult with us.
Every unit comes with a suction tube, mounting bracket, a multilanguage manual (RUS, DE, ES, FR, ITA, EN, PT) and a seal kit containing an upper piston seal, lower piston seal, suction seal and a small quantity of grease.
The suction tube length is 1.5m long and 10mm diameter for the type 0.2 - 2.0% and 16mm diameter for the type 0.5/1.0 - 4.0%.
These types are the standard AG (Agriculture) models that come with NBR seals which are ot be used with fertilizer solutions and not to be used with acids.
For a complete overview and more information on the chemichal compatibility table please consult with us in order to select the right model for your application.
Installation can be done in different ways: In-line, dual, manual by-pass, multi zone manual by-pass and controlled by-pass.
For spare parts and spare part kits please consult with us.
Every unit comes with a suction tube, mounting bracket, a multilanguage manual (RUS, DE, ES, FR, ITA, EN, PT) and a seal kit containing an upper piston seal, lower piston seal, suction seal and a small quantity of grease.
The suction tube length is 1.5m long and 10mm diameter for the type 0.2 - 2.0% and 16mm diameter for the type 0.5/1.0 - 4.0%.
These types are the standard AG (Agriculture) models that come with NBR seals which are ot be used with fertilizer solutions and not to be used with acids.
For a complete overview and more information on the chemichal compatibility table please consult with us in order to select the right model for your application.
Installation can be done in different ways: In-line, dual, manual by-pass, multi zone manual by-pass and controlled by-pass.
For spare parts and spare part kits please consult with us.
